3,4,9,10-Perylenetetracarboxylic dianhydride

  • Name: 3,4,9,10-Perylenetetracarboxylic dianhydride
  • CAS: 128-69-8
  • Purity: 99%
Inquiry

Details

Manufacturer supply 3,4,9,10-Perylenetetracarboxylic dianhydride 128-69-8 with sufficient stock and high standard

  • Molecular Formula: C24H8O6
  • Molecular Weight: 392.324
  • Appearance/Colour: dark red powder
  • Melting Point: 350 °C
  • Refractive Index: 1.969
  • Boiling Point: 755.8 °C at 760 mmHg
  • Flash Point: 329.9 °C
  • PSA： 86.74000
  • Density: 1.764 g/cm3
  • LogP: 4.35840

3,4,9,10-Perylenetetracarboxylic dianhydride(Cas 128-69-8) Usage

General Description

Perylene-3,4,9,10-tetracarboxylic dianhydride (PTCDA) is a perylene derivative which forms highly crystalline films and dyes that can be used for a majority of electronic and opto-electronic applications. It provides a high electron mobility due to its low intermolecular distance which results in π-π conjugation.

Flammability and Explosibility

Notclassified

InChI:InChI=1/C48H22O15/c49-41(50)25-15-13-21-19-9-1-5-17-7-3-11-23(27(17)19)31-29(21)33(25)35(43(53)54)37(45(57)58)39(31)47(61)63-48(62)40-32-24-12-4-8-18-6-2-10-20(28(18)24)22-14-16-26(42(51)52)34(30(22)32)36(44(55)56)38(40)46(59)60/h1-16H,(H,49,50)(H,51,52)(H,53,54)(H,55,56)(H,57,58)(H,59,60)

128-69-8 Relevant articles

Inorganic/organic small molecular semiconductor self-assembly to functional core-shell nanoarchitectures for ultrasensitive chemiresistors to aniline vapor

Wang, Ke,Yang, Hui,Qian, Xuemin,Xue, Zheng,Li, Yongjun,Liu, Huibiao,Li, Yuliang

, p. 11542 - 11547 (2014)

We developed a new method combining the ...

A 3, 9 - perylene dicarboxylic acid preparation method

-

Paragraph 0033; 0034; 0035, (2019/03/23)

The invention discloses a 3, 9 - perylen...

Preparation method and application of novel perylene drug molecule with biological activity

-

Paragraph 0028-0030, (2018/12/14)

The invention discloses a preparation me...

Preparation method and application of novel perylene acid medicinal molecule with antineoplastic activity

-

Paragraph 0070; 0071; 0072, (2019/01/08)

The invention discloses a preparation me...

Preparation method of Lumogen Red F300

-

Paragraph 0026; 0034; 0035; 0036; 0042; 0046, (2017/07/20)

The invention relates to Lumogen Red F30...

128-69-8 Process route

3,4,9,10-perylene tetracarboxyxlic acid diimide
81-33-4

3,4,9,10-perylene tetracarboxyxlic acid diimide

perylene-3,4,9,10-tetracarboxylic acid 3,4:9,10-dianhydride
128-69-8

perylene-3,4,9,10-tetracarboxylic acid 3,4:9,10-dianhydride

Conditions
Conditions Yield
With sulfuric acid; In water; at 210 ℃; for 4h;
With hexafluoroantimonic acid; sulfuric acid; at 60 - 125 ℃; for 8h; Reagent/catalyst; Temperature; Concentration;
3,4,9,10-perylene tetracarboxyxlic acid diimide; With sulfuric acid; at 220 ℃; for 2h;
With potassium hydroxide; In water; at 90 ℃; for 1h; Further stages; Darkness; Inert atmosphere;
175 g
With sulfuric acid; at 220 ℃; for 2h;
162 g
With sulfuric acid; at 20 - 220 ℃; for 2h;
175 g
N-(1-hexylheptyl)perylene-3,4,9,10-tetracarboxylic-3,4-anhydride-9,10-imide
110590-84-6

N-(1-hexylheptyl)perylene-3,4,9,10-tetracarboxylic-3,4-anhydride-9,10-imide

N-(1-hexylheptyl)-perylene-3,4,9,10-tetracarboxylic-3,4-carboximide-9,10-anhydride
130296-37-6

N-(1-hexylheptyl)-perylene-3,4,9,10-tetracarboxylic-3,4-carboximide-9,10-anhydride

perylene-3,4,9,10-tetracarboxylic acid 3,4:9,10-dianhydride
128-69-8

perylene-3,4,9,10-tetracarboxylic acid 3,4:9,10-dianhydride

Conditions
Conditions Yield
With potassium hydroxide; In tert-butyl alcohol; for 0.166667h; Heating;
63%
With potassium hydroxide; In tert-butyl alcohol; Heating;
40%

128-69-8 Upstream products

  • 81-32-3
    81-32-3

    perylene-3,4,9,10-tetracarboxylic acid

  • 38687-17-1
    38687-17-1

    1,1'-binaphthyl-4,4',5,5'-tetracarboxylic acid dianhydride

  • 5521-31-3
    5521-31-3

    N,N'-Dimethylperylene-3,4,9,10-biscarboximide

  • 82718-41-0
    82718-41-0

    1,1'-binaphthyl-4,4',5,5',8,8'-hexacarboxylic acid dianhydride sodium salt

128-69-8 Downstream products

  • 128-65-4
    128-65-4

    2,9-diphenylanthra[2,1,9-def:6,5,10-d'e'f']diisoquinoline-1,3,8,10(2H,9H)-tetraone

  • 85895-86-9
    85895-86-9

    2-(2-amino-phenyl)-benz[4,5]imidazo[2,1-a ]anthra[2,1,9-def ;6,5,10-d'e'f' ]diisoquinoline-1,3,8-trione

  • 59442-38-5
    59442-38-5

    N,N’-bis(propyl)perylene-3,4,9,10-bis(dicarboximide)

  • 83054-86-8
    83054-86-8

    2,9-Bis-(4-tert-butyl-cyclohexyl)-anthra[2,1,9-def;6,5,10-d'e'f']diisoquinoline-1,3,8,10-tetraone
